High Cycle Life
Greater than 5000 cycles @ 80% DOD, 25°C
Longer lifespan
Low-maintenance batteries with stable chemical composition
Built-in circuit protection
Battery Management System (BMS) prevents overcharging and over discharging, extends battery lifespan, and monitors battery status
Improved storage capability
Due to its extremely low self-discharge (LSD) rate and no risk of sulfation, our 200ah lifepo4 lithium battery can be stored for up to 6 months.
The lithium battery 200 ah battery pack consist of modular and expandable design to achieve the desired voltage and capacity.
Uses Lithium LiFePO4 battery for its safety, stability, and long cycle life. 200ah lifepo4 lithium battery pack , typically offers a high cycle life, greater than 5000 cycles.
Pre-tested wiring and factory-tested for quick installation.
A BMS (Battery Management System) is essential for monitoring and protecting the 200ah lifepo4 lithium battery pack. It helps balance the cells, prevents overcharging, over-discharging, over-current, high/low-temperature protection and monitors temperature to ensure safe and optimal performance.
The 200ah lifepo4 lithium battery pack is designd with LCD display screen with button design.
| Model | Raisun RSB61-25.6V 200Ah |
| Battery Type | LifePO4 |
| Typical Capacity(Ah) | 200Ah |
| Typical Voltage(V) | 25.6V |
| Connection | 2P8S |
| Voltage Working Range(V) | 21.6V-29.2V |
| Working Temperature(℃) | Charge: 0℃ ～ +55℃ Discharge: -20℃ ～ +60℃ |
| Storage Temperature(℃) | -20℃ ～ +35℃ |
| Nominal Capacity(kWh) | 5.12kWh |
| Max. Charge Current(A) | 100A |
| Max. Discharge Current(A) | 100A |
| Cycle Life | ＞5000 |
| SOC Accuracy | ＜8% |
| Weight(kg) | 53kg |
| Dimensions(mm) | 185×450×580mm |
| IP Grade | IP54 |
| Transportation SOC | 30% |
| Cooling | Nature |
| Communication | RS232, RS485, CAN |
| Certifications | MSDS, UN38.3, RoHS, CE |
