The rated output power is 1500VA/1500W, which can provide stable power supply for households and small commercial places, and meet the daily electricity demand.
Equipped with USB, RS232, GPRS and WIFI communication interfaces, it is convenient to realize remote monitoring and management, and improve the convenience of use.
The maximum solar charging current is 80A, and the maximum PV input power is 1500W. It efficiently uses solar resources to charge the battery and provides reliable backup power.
With overcharge, overdischarge and overload protection functions, it can protect the safe operation of the battery and inverter and prolong the life of the equipment.
It is suitable for different input voltage ranges, and the frequency range is 50Hz/60Hz, suitable for the use of various home appliances and office equipment.
Model | Raisun RSI44-1.5KW |
Phase | 1-Phase |
Maximum PV Input Power | 1500W |
Rated Output Power | 1500VA/1500W |
Maxium Solar Charging Current | 80A |
INPUT | |
Voltage | 230VAC |
Selectable Voltage Range | 170~280VAC(For Personal Computers) |
90~280VAC(For Home Appliances) | |
Frequency Range | 50Hz/60Hz(Auto sensing) |
OUTPUT | |
AC Voltage Regulation(Batt.Mode) | 230VAC±5% |
Surge Power | 3000VA |
Efficiency(Peak) PV to INV | 98% |
Efficiency(Peak) Battery to INV | 94% |
Transfer Time | 10 ms(For Personal Computers); 20ms(For Home Appliances) |
BATTERY & AC CHARGER | |
Battery Voltage | 12VDC |
Floating Charge Voltage | 13.5VDC |
Overcharge Protection | 16VDC |
Maximum AC Charge Current | 60A |
SOLAR CHARGER | |
Maximum PV Array Power | 2000W |
MPPT Range Operating Voltage | 90~400VDC |
Maximum PV Array Open Circuit Voltage | 450VDC |
Maximum Charging Current | 80A |
Maximum Efficiency | 98% |
PHYSICAL | |
Dimension, D×W×H | 348*270*95mm |
Net Weight(kgs) | 4 |
Comumication Interface | USB/RS232/GPRS/WIFI |
OPERATING ENVIRONMENT | |
Mumidity | 5% to 95% Relative Humidity(Non-condensing) |
Operating Temperature | 0℃ ~ 55℃ |
Storage Temperature | -15℃ ~ 60℃ |
